What Is Dual Personality Sfp Slots

LX, LH, and BX with four SFP slots on all 24- and 48-port Gigabit Ethernet models. Fast Ethernet 24- and 48-port models have two SFP slots and two RJ-45 Gigabit uplinks; 8-port models have two dual-personality ports supporting either SFP or RJ-45 Gigabit uplinks. Dual-personality (RJ.

What Is Dual Personality Sfp Slots Free

HP ProCurve was the name of the networking division of Hewlett-Packard from 1998 to 2010 and associated with the products that it sold. The name of the division was changed to HP Networking in September 2010. Please use HP Networking Products for an actual list of products.

The HP ProCurve division sold network switches, wireless access points, WANrouters, and Access Control Servers/Software under the 'HP ProCurve' brand name.

  1. The dual personality means that you can only have SPF or RJ45 active. If you look at the switch front face you will see that activity lights probably say “48/52”, “47/50”, “46/51” and “45/49.” Or some number combination like that. So port 48 and 52 are linked and only one of them can be active.
  2. Oct 01, 2019  SFP module types support both single and multimode fiber and Cat5, Cat6, Cat6a and Cat7 twisted pair copper. SFP modules designed for use with fiber support a variety of wavelengths and maximum distances up to 2 km with multimode and 40 km with single mode.
  • 1Switching
    • 1.5Managed edge switches
  • 2Routing
  • 3Mobility
  • 4Management Software
  • 5Security
  • 6Accessories
  • 7ProCurve ONE

Switching[edit]

What

Core Switches[edit]

  • 8212zl Series - (Released September 2007) Core switch offering, 12-module slot chassis with dual fabric modules and options for dual management modules and system support modules for high availability (HA). IPV6-ready, 692 Gbit/s fabric. Up to 48 10GbE ports, 288 Gb ports, or 288 SFPs. Powered by a combination of either 875W or 1500W PSUs, to provide a maximum of 3600W (5400W using additional power supplies) of power for PoE.

Datacenter Switches[edit]

  • 6600 Series - (Released February 2009) Datacenter switch offered in five versions. There are four switches with either 24 or 48 Gb ports, with two models featuring four 10GbESFP ports. There is also a 24 port 10GbE version. All of these feature front to back cooling and removable power supplies.[1]

Interconnect Fabric[edit]

  • 8100fl series - Chassis based, 8 or 16 slot bays. Supports up to 16 10GE ports / 160 Gigabit Ethernet Ports / 160 SFPs.

Distribution/Aggregator[edit]

  • 6200yl - Stackable switch, Layer 3, with 24 SFP transceiver ports, and the capability of 10GE ports
  • 6400cl series - Stackable switch, Layer 3, with either CX4 10GE ports or X2 10GE ports
  • 6108 - Stackable switch, with 6 Gb ports, and a further 2 Dual Personality Gb ports (either Gb or SFPs)

Managed edge switches[edit]

Entry level[edit]

2530 and 2620 lines are Aruba/HPE branded and included for comparison purposes only
PropertyOld version, no longer supported: 2500Old version, no longer supported: 2510Old version, no longer supported: 2520Current stable version:2530Old version, no longer supported: 2600Old version, no longer supported: 2610Current stable version:2620
StatusDiscontinuedCurrentDiscontinuedCurrent
Released2000July 200720022008September 2011
LayerLayer 2Layer 3 (lite)Layer 3 (lite) static routingLayer 3 (lite) static & RIP routing
Ports12 or 24 10/100 ports with 2 proprietary Gb transceiver slots.24 (fanless) or 48 (incl. fan) 10/100 ports including 2 Dual Personality Ports (Gb or SFPs).
G models: 20 or 44 Gb ports with 4 Dual Personality Ports (4 x Gb or SFPs).
8 or 24 (PoE or non-PoE). GB and non-GB8, 24 or 48 10/100 ports including 1 or 2 Dual Personality Ports (1 or 2 x Gb or SFPs).24 or 48 (10/100 with 2 Gb ports and 2 SFP ports (no Dual Personality)[2]24 or 48 (PoE and non-PoE) with 2 SFP ports [1]
CPU62.5Mhz264-300Mhz266Mhz800Mhz266Mhz300Mhz400Mhz
Memory26KB64MB (128MB 2510-48)128MB DDR2256MB DDR332MB128MB512MB
Packet buffer6MB385KB (24), 768KB (24G)
512KB (48), 1.5MB (48G)
384KB (512KB on GB models)1.5MB (8,24), 3MB(48)1MB (24), 2MB (48)1MB (24), 2MB (48)
Last soldFebruary 2010February 2014CurrentFebruary 2009May 2012Current
Spec ref[2][3][4][5][6][7][8]

Mainstream[edit]

2920 line is Aruba/HPE branded and included for comparison purposes only
PropertyOld version, no longer supported: 2800Old version, no longer supported: 2810Old version, no longer supported: 2900Old version, no longer supported: 2910alOlder version, yet still supported: 2920Old version, no longer supported: 3400clOld version, no longer supported: 3500Old version, no longer supported: 3500yl
StatusDiscontinuedCurrentDiscontinued
Released2006200620092004February 2007
LayerLayer 2 with Layer 3 routingLayer 2Layer 2 with Layer 3 routingLayer 3
Ports20 or 44 Gb ports with 4 Dual Personality Ports (4 x Gb or SFPs).20 or 44 Gb ports with 4 Dual Personality Ports (4 x Gb or SFPs)20 or 44 Gb ports with 4 Dual Personality Ports (2 x Gb or SFPs)
Additionally includes four 10GE ports (two CX-4 and two capable of housing optional 10GE optical transceivers).
20 or 44 Gb ports with 4 Dual Personality Ports (4 x GborSFPs)
Supports up to four optional 10 Gigabit ports in CX4 and / or SFP+. Two versions support PoE and PoE+[3]
20 or 44 Gb port switch, and 4 x Dual Personality Ports (2 x Gb or SFPs). Also capable of supporting 10GE ports.20 or 44 10/100 port switches with two models supportingPoE functionality, and 4 x Dual Personality Ports (2 x Gb or SFPs).[4][5]20 or 44 Gb port switch with PoE functionality, and 4 x Dual Personality Ports (2 x Gb or SFPs). Also capable of supporting 10GE ports.
CPU266Mhz264Mhz667Mhz515Mhz625Mhz266Mhz666Mhz
Memory64MB64MB515MB512MB128MB256MB
Packet buffer768KB (24G), 1.5MB (48G)13.5MB (24G), 22.5MB (48G)6MB11.25MB2MB
Last soldDecember 2009August 2013October 2009May 2014March 2018 (August 2018 PoE)March 2009June 2014
Spec ref[9][10][11][12][13][14][15]

Chassis/Advanced[edit]

SeriesStatusReleasedLayerSizesComments
5400zlCurrentLayer 36 or 12 slot bays. Supports up to 48 10GE ports, 288 Gb ports, or 288 SFPsPowered by a combination of either 875W or 1500W PSU's, to provide a maximum of 3600W (5400W using additional powersupplies) of power for PoE
4200vlDiscontinued4 or 8 slot bays. Supports up to 192 10/100 ports or 128 Gb ports, or 32 SFPs.

Web managed switches[edit]

  • 1800 series - Stackable, Fanless 8 or 24 Gb ports. The 1800-24G also has 2 Dual Personality Ports (2 x Gb or SFP). No CLI or SNMP management.
  • 1700 series - Stackable, Fanless 7 10/100 ports plus 1 Gb or 22 10/100 ports plus 2 Gb. The 1700-24 also has 2 Dual Personality Ports (2 x Gb or SFPs). No CLI or SNMP management.

Unmanaged Switches[edit]

  • 2300 series
  • 2124
  • 1400 series
  • 408

Routing[edit]

WAN Routers[edit]

  • 7000dl - Stackable WAN Routers with modules for T1/E1, E1+G.703, ADSL2+, Serial, ISDN, and also IPsecVPN.

German company .vantronix marketed software products until 2009.[6][7]

Mobility[edit]

Due to country laws, ProCurve released different versions of their wireless access points and MultiService Access points.

Should gambling be legalized and regulated persuasive speech inspired the board game Monopoly. You can bet on individual numbers, combinations of numbers, or colors, before the wheel is spun, by placing chips in appropriate sections on the betting layout The wheel is spun by a casino should gambling be legalized and regulated persuasive speech employee, who then spins a ball along the wheel in the. These are should gambling be legalized and regulated persuasive speech called hole or pocket cards. Slot machines in current times have become 1 of the should gambling be legalized and regulated persuasive speech most endeared attractions in gambling dens. Essay Should Gambling Be Legalized? Gambling is defined as any behavior that includes the risking of money or valuables on the result of a game, contest, or another event that is dependent on chance. Gambling is an impulse-control disorder that is progressive in its. Should Gambling Be Legalized Essay - Should Gambling Be Legalized. Gambling is the risking of money or other possessions that’s mostly depends on chance and luck, even tough some forms of gambling may be influenced by skills. Should gambling be legalized and regulated persuasive speech.

MultiService Mobility / Access Controllers[edit]

Personality

The MSM Access and Mobility Controllers support security, roaming and quality of service across MSM Access Points utilising 802.11 a/b/g/n wireless technology.[8]

  • MSM710 - Supports up to 10 x MSM Access points. Supports up to 100 Guest Users.
  • MSM730 - Supports up to 40 x MSM Access points. Supports up to 500 Guest Users.
  • MSM750 - Supports up to 200 x MSM Access points. Supports up to 2000 Guest Users.
  • MSM760 - Supports 40 x MSM Access Points, plus license support up to 200
  • MSM765 - Supports 40 x MSM Access Points, plus license support up to 200. This is a module form, and based on the ProCurve ONE.

MultiService Access Points[edit]

Most access points are designed to work in controlled mode: a controller manages and provides authentication services for them.

  • MSM310 - Single 802.11a/b/g radio. Includes 2.4 GHz dipole antennas
  • MSM310-R - External use. Single 802.11a/b/g radio. Includes 2.4 GHz dipole antennas
  • MSM313 - Integrated MSM Controller + single radio Access Point
  • MSM313-R - External Use. Integrated MSM Controller + single radio Access Point
  • MSM317 - Single 802.11b/g radio, with integrated 4 port switch[8][9]
  • MSM320 - Dual radios (802.11a/b/g + 802.11a/b/g) for outdoor deployment options. Includes 2.4 GHz dipole antennas. Supports PoE.
  • MSM320-R - External use. Dual radios (802.11a/b/g + 802.11a/b/g). Includes 2.4 GHz dipole antennas. Supports PoE.
  • MSM323 - Integrated MSM Controller + dual radio Access point.
  • MSM323-R - External Use. Integrated MSM Controller + dual radio Access point.
  • MSM325 - Dual radios (802.11a/b/g + 802.11a/b/g) including RF security sensor. Requires PoE
  • MSM335 - Triple radios (802.11a/b/g + 802.11a/b/g + 802.11a/b/g RF security sensor)
  • MSM410 - Single 802.11 a/b/g/n radio. Requires PoE. Internal antenna only.
  • MSM422 - Dual-radio 802.11n + 802.11a/b/g.
  • MSM460 - Dual-Radio 802.11a/b/g/n. Only internal 3x3 MIMO Antenna. Requires PoE.
  • MSM466 - Same as MSM460 but with external 3x3 MIMO antenna connectors, no internal antenna. Requires PoE.

Centralised wireless[edit]

  • Wireless Edge Services Module - Controls Radio ports, and is an integrated module that fits into ProCurve Switches 5300xl / 5400zl / 8200zl only. Redundant Module available for failover. Supports the following Radio Ports:
  • RP-210 - Single 802.11b/g radio and integrated antenna
  • RP-220 - Dual-radio design (one 802.11a and one 802.11b/g); plenum rated; external antennas required
  • RP-230 - Dual-radio design (one 802.11a and one 802.11b/g); features internal, integrated antennas

Wireless access points[edit]

  • M110 - Single 802.11a/b/g radio
  • M111 - Wireless Client Bridge including dual band antennas
  • AP-530 - Wireless access point; Dual radios support simultaneous 802.11a and 802.11b/g transmissions. The AP-530 has two integrated radios (one of which supports 802.11a/b/g; the other of which supports 802.11b/g). The AP supports the Wireless Distribution System.
  • AP-420 - Wireless access point; Features a single, dual-diversity 802.11b/g radio.
  • AP-10ag - Wireless access point; Dual radios support simultaneous 802.11a and 802.11b/g transmissions.

Management Software[edit]

ProCurve Manager' (PCM) is a network management suite for products by ProCurve.

ProCurve Manager[edit]

ProCurve Manager comes in two versions; a base version supplied both free of charge with all managed ProCurve Products and also for download, and a 'Plus' version that incorporates more advanced functionality and also enables plugin support. There is a 60-day trial version including all modules. Both derive from the trial version and need to be activated via Internet.

The Plus version can also be implemented in HP OpenViewNetwork Node Manager for Windows. The software ProCurve Manager is predominantly for ProCurve products.

Protocols[edit]

  • PCM uses Link Layer Discovery Protocol (LLDP, Cisco Discovery Protocol (CDP) and FDP (Foundry) for detecting network devices
  • For identification and deep inspection of network devices SNMP V2c or V3 is used.
  • Network traffic is analysed using RMON and sFlow.

Plugins[edit]

  • IDM (Identity Driven Manager) - Add-on Module for PCM+; contains Intranet Network Access Security using 802.1X; compatible with MicrosoftNetwork Access Protection (NAP) since Version IDM V2.3
  • NIM (Network Immunity Manager) - Add-On Module for PCM+ v2.2 and above; contains Intranet Intrusion Detection and Network Behavior Anomaly Detection (NBAD) using sFlow
  • PMM (ProCurve Mobility Manager) - Add-on Module for PCM+; contains Element Management for ProCurve Access Points (420/520/530) starting from Version PMM V1; WESM Modules and Radio Ports are supported since Version PMM V2. Since PMM v3, the MSM Access Points and Controllers are now supported[10]

Security[edit]

What is dual personality sfp slots list

Network Access Control with Endpoint testing[edit]

  • ProCurve Network Access Controller 800 - Management and Security for Endpoints when they access the Network

Firewall[edit]

The Threat Management Services Module is based on the ProCurve ONE Module, and is primarily a firewall with additional Intrusion-prevention system and VPN capabilities[11][12]

Accessories[edit]

External power supplies[edit]

  • ProCurve 600 Redundant external power supply - supports one of six times Redundant Power for series 2600-PWR (not series 2600 w/o PWR), 2610, 2800, 3400cl, 6400cl and 7000dl as well as two times optional External PoE Power for series 2600-PWR, 2610-PWR or mandatory External PoE Power for series 5300 with xl 24-Port 10/100-TX PoE Module only
  • ProCurve 610 External power supply - supports four times optional External PoE Power for series 2600-PWR, 2610-PWR, or mandatory External PoE Power for series 5300 with xl 24-Port 10/100-TX PoE Module only
  • ProCurve 620 Redundant/External power supply - supports two times optional External PoE Power for series 3500yl and two times Redundant Power for series 2900, 3500yl and 6200yl
  • ProCurve Switch zl power supply shelf - supports two times optional External PoE Power for series 5400zl and 8200zl; must be additionally equipped with max. two 875W or 1500W (typical) ProCurve Switch zl power supplies

GBICs and optics[edit]

ProCurve have a range of Transceivers, GBICs and 10GbE optics for use within ProCurve devices.

Transceivers[13] are used in the unmanaged 2100 & 2300 series, and the managed 2500 series of switches

TypeCable TypeMaximum DistanceNotes
Gigabit Stacking KitInterconnect Cable59 cm2 x HSSDC Gigabit Transceiver ports.
Gigabit SX TransceiverMultimodeup to 550 m1000BASE-SX, -SC port.
Gigabit LX TransceiverSinglemode or Multimode10 km or 550 m1000BASE-LX, -SC port.
100/1000-T TransceiverCategory 5 cable plus100 mRJ-45 port.
100-FX TransceiverMultimode2 km full duplex or 412 m half duplex100BASE-FX port.

GBICs[14] are used for most switches for 100 Mbit/s and 1000 Mbit/s fiber connectivity. All fiber GBICs have an LC presentation.

TypeCable TypeMaximum DistanceNotes
100BASE-FXMultimode2 km full duplex or 412 m half duplex
100BASE-BX10-DSinglemodeup to 10 km
100BASE-BX10-USinglemodeup to 10 km
1000BASE-SXMultimodeup to 550 mDependant on fiber cable quality
1000BASE-LXMultimode2 to 550 m
1000BASE-LXSinglemode2 to 10,000 mCompliant with IEEE 1000BASE-LX10 standard
1000BASE-LHSinglemode10 to 70,000 mAttentuators may be required dependant on distance.
1000BASE-BX-DSinglemode0.5 to 10,000 m
1000BASE-BX-USinglemode0.5 to 10,000 m
1000BASE-T TransceiverCat 5 cable plus100 m

ProCurve ONE[edit]

HP ProCurve ONE Services zl Module[edit]

The HP ProCurve ONE Services zl Module is an x86-based server module that provides two 10-GbE network links into the switch backplane. Coupled with ProCurve-certified services and applications that can take advantage of the switch-targeted API for better performance, this module creates a virtual appliance within a switch slot to provide solutions for business needs, such as network security. The ProCurve ONE Services zl Module is supported in the following switches:

  • HP ProCurve Switch 5406zl
  • HP ProCurve Switch 5412zl
  • HP ProCurve Switch 8212zl

What Is Sfp Connector

The following applications have completed, or will complete the ProCurve ONE Integrated certification on the HP ProCurve Services zl Module in early 2009.

What Is Sfp Slot

Data center automation

Location

Wireless IPS

Network management

VoIP / Unified Communications

Video distribution

What Is Dual Personality Sfp Slots Online

Discontinued Products[edit]

  • 1600M - stackable Layer 2 switch
  • 2400M - stackable Layer 2 switch
  • 2424M - stackable Layer 2 switch
  • 4000M - modular Layer 2 switch
  • 8000M - modular Layer 2 switch
  • 9400 - modular Layer 3 Router
  • AP 520 - Access Point
  • 4100gl - modular Layer 2 switch
  • 2700 series - unmanaged Layer 2 switch
  • 9300m series - modular Layer 3 Router
  • ProCurve Access Controller Series 700wl
  • 745wl
  • ACM (Access Control Module) for the 5300xl only
  • 5300xl series - Chassis based, Layer 3, in either 4 or 8 slot bays.

References[edit]

  1. ^O'Hanlon, Charlene (2009-01-26). 'HP flexes datacenter muscle with new switch'. Channel Insider. Retrieved 2009-05-30.
  2. ^Duffy, Jim (2008-06-02). 'HP ProCurve refreshes edge switches'. www.pcworld.idg.com.au. Retrieved 2009-05-30.
  3. ^Duffy, Jim (2009-03-17). 'ProCurve unveils new SMB switches'. Network World. Archived from the original on 2011-06-15. Retrieved 2009-05-28.
  4. ^April, Carolyn (2009-06-15). 'HP ProCurve Rolls Out New 10/100 Switches'. Channel Insider. Retrieved 2009-06-15.
  5. ^Hickey, Andrew (2009-06-15). 'ProCurve Bulks Up 3500 Switch Series'. ChannelWeb. Archived from the original on 2009-06-17. Retrieved 2009-06-15.
  6. ^'High-secure products based on OpenBSD'. vantronix web site. 2009. Archived from the original on June 5, 2009. Retrieved August 30, 2011.
  7. ^'ProCurve ONE Alliance: .vantronix'. vantronix web site. 2009. Archived from the original on February 1, 2009. Retrieved August 30, 2011.
  8. ^ abHickey, Andrew (2009-06-01). 'ProCurve Goes Mobile, Eyes Convergence'. ChannelWeb. Archived from the original on 2013-01-20. Retrieved 2009-06-02.
  9. ^Cox, John (2009-06-01). 'HP ProCurve converges wireless and wired network access'. Network World. Archived from the original on 2009-06-03. Retrieved 2009-06-02.
  10. ^Cox, John (2009-06-01). 'HP ProCurve converges wireless and wired network access'. Network World. Archived from the original on 2009-06-03. Retrieved 2009-06-02.
  11. ^Fratto, Mike (2009-04-29). 'New ProCurve Threat Module: Flexibility Requires Planning'. Information Week. Retrieved 2009-05-28.
  12. ^Walsh, Lawrence (2009-04-27). 'HP Unveils ProCurve Firewall, Security Ambitions'. Channel Insider. Retrieved 2009-05-30.
  13. ^'FAQs for ProCurve Transceivers'. ProCurve.com. Retrieved 2009-05-28.
  14. ^'FAQs for ProCurve GBICs'. ProCurve.com. Retrieved 2009-05-30.
